Kirisun DR600 Service Manual

DR600 Service Manual
2RS1-16-560J
R flake resistor
1608, 56Ω±5%
2
R3052, L4000
2RS1-16-511J flake resistor 1608, 510Ω±5% 1 R4000
2RS1-16-203J R flake resistor 1608, 20K±5% 1 R4001
2RS1-16-513J R flake resistor 1608, 51K±5% 1 R6001
2RS1-16-273J
R flake resistor
1608, 27K±5%
2
R6008, R6010
2RS1-16-362J R flake resistor 1608, 3.6K±5% 1 R6011
1TC1-UMC4 R patch compound tube UMC4, NPN/PNP compound tube 2 U1000, U3000
1IS1-AD9864 IF digital system
AD9864, LFCSP-N48_B7X6_75_P0_5,
pb-free
1 U4000
1IS1-LM2941S Patch specialized IC LM2941S/TO-236, 5PIN, pb-free 1 U5000
5FQ1-LFCN-400 Low pass filter
LFCN-400, 8.5W, DC to 400MHz, FV1206,
Mini-Circuits
1 U5002
5OT1-12R8-CEC3-05
03
R patch temperature
compensated crystal
oscillator
NT5032SA/NT5032SC, 12.8MHz±2.5PPm,
5.0*3.2*1.6mm
1 X1000
5FC1-DSF51R6M-07
05
R patch crystal filter,
PT568/78/72/62/65/68/D
R55/DM58/3208/V68/E6
6
DSF753SBF, 51.65MHz±4KHz/3dB,
7.0*5.0*1.3, DP77/CD37/RD47/AP57
2 Z3000, Z3001
2LW1-20UC-120J patch winding inductor
2012, 12nH±5%, ceramic core
(C2012C-12NJ)
1 L1016
1DV1-1SV305 R patch varactor 1SV305 8
D1002, D1003, D1004, D1005, D1006,
D1007, D1008, D1009
2LW1-16UC-180J R patch winding inductor
1608, 18nH±5%, ceramic core
(C1608CB-18NJ)
1 L1013
2LL1-16-R22K R laminated inductor 1608, 0.22μH±10%(MLF1608DR22K TA00) 1 L3017
2CC1-16-C0G500-15
1J
R flake multi-layer
capacitor
1608, 150P±5%, 50V, C0G 1 C3058
2RS1-16-561J R flake resistors 1608, 560Ω±5% 1 R4005
2CC1-16-C0G500-2R
5B
R R flake multi-layer
resistor
1608, 2.5P/2.4P±0.1P, 50V, C0G 1 C1073
59
