Kirisun DR600 Service Manual

DR600 Service Manual
2LW1-20UC-180G patch winding inductor
ceramic core LQW2UAS18NG00 0805
18nH±2%
1 L1017
2CC1-16-C0G500-3R
0B
flake multi-layer
capacitor
1608, 3P±0.1P, 50V, C0G 2 C3002, C2018
2RS1-16-820J flake resistor 1608, 82Ω±5% 1 R3000
3CR7-SMA-50KWE-2 RF coaxial connector
SMA-50KWE-2, 5PIN, 90 degrees,23mm
long. pitch: 2.54mm
2 J3000, J3002
3CB3-A2548WV-2X1
3P
Board-board connector
2*13 socket, 180 degrees, spacing 2.54mm,
40.64X9X9.1mm, manufacturer: JOINT
TECH
1 J6000
Table 2 400-470 Parts List (Tx Module Section)
Part No. Acccessory Names Description Quantity Location
3FW1-42932-302320 R patch fuse 429003/433003/466003, 3216, 3A/32V 1 CB400
1DR1-MM3Z12VT1G
Electrostatic-proof zener
diode
MM3Z12VT1G, 3V, SOD323, pb-free 1 D400
1DS1-HSC277
R patch switch diode
(production halt)
HSC277, 1608 1 D100
1DV1-1SV278
R patch varactor
1SV278(T1)
2
D105, D110
1DV1-1SV305 R patch varactor 1SV305 8
D101, D102, D103, D104, D106, D107,
D108, D109
1IS1-LM2941S Patch specialized IC
LM2941S/TO-236, 5PIN, Low dropout
voltage regulator, pb-free
1 U400
1IS1-SKY72310 PLL chip
SKY72310, 24 pin QFN 4mmX4mm
pb-free(QFN-N24_B4x4-P0_5), pb-free
1 IC100
1IS1-SPF5122Z Patch specialized IC
SPF5122Z/2mm*2mm, 8PIN, 50MHz-4GHz
low noise amplifier, pb-free
1 IC304
1IS1-TC75S51F
Patch single operational
TC75S51F, SSOP5-P-0.95
2
IC300, IC301
60
