Kirisun DR600 Service Manual

DR600 Service Manual
amplification IC
1IS1-XC6209F302PR
Patch voltage
stabilization IC
XC6209F302PR, SOT-89-5, stable 3.0V
voltage
1 IC101
1IS1-XC6209F332PR
Patch voltage
stabilization IC
XC6209F332PR, SOT-89-5, stable 3.3V
voltage
1 IC103
1IS1-XC6209F502PR
Patch voltage
stabilization IC
XC6209F502PR, SOT-89-5, stable 5.0V
voltage
4 IC102, IC104, IC105, IC302
1TC1-UMC4 R patch compound tube UMC4, NPN/PNP compound tube 1 U100
1TF1-2SJ243 R patch FET 2SJ243-SMD 1 Q104
1TT1-2SC3356-R24
R patch triode
2SC3356-R24, SOT23, NPN
3
Q105, Q106, Q202
1TT1-2SC4617-R R patch triode 2SC4617-R(BR), EMT3 1 Q101
1TT1-DTC114YE patch triode Digital triode DTC114YE-SMD 2 Q204, Q400
1TT1-FMMT717TA R patch triode FMMT717A, PNP, SOT23 1 Q203
2CC1-16-C0G500-10
0D
R flake multi-layer
capacitor
1608, 10P±0.5P, 50V, C0G 2 C188, C189
2CC1-16-C0G500-10
1J
R flake multi-layer
capacitor
1608, 100P±5%, 50V, C0G 64
C161, C166, C167, C182, C184, C186,
C199, C208, C212, C214, C216, C224,
C228, C234, C239, C242, C246, C255,
C289, C291, C295, C297, C300, C301,
C302, C303, C304, C305, C306, C307,
C308, C309, C310, C311, C312, C315,
C316, C317, C320, C321, C322, C323,
C340, C341, C344, C345, C102, C106,
C111, C113, C117, C119, C123, C124,
C138, C140, C142, C144, C146, C150,
C151, C153, C157, C160,
2CC1-16-C0G500-10
2J
flake multi-layer
capacitor
1608, 1000P±5%, 50V, C0G 8
C175, C240, C325, C329, C332, C334,
C342, R333
2CC1-16-C0G500-12
0J
R flake multi-layer
capacitor
1608, 12P±5%, 50V, C0G 3 C131, C132, C230
2CC1-16-C0G500-12
R flake multi-layer
1608, 120P±5%, 50V, C0G
1
C244
61
