Kirisun DR600 Service Manual

DR600 Service Manual
1J
capacitor
2CC1-16-C0G500-18
0J
R flake multi-layer
capacitor
1608, 18P±5%, 50V, C0G 1 C171
2CC1-16-C0G500-1R
0B
flake multi-layer
capacitor
1608, 1P±0.1P, 50V, C0G 10
C129, C133, C135, C169, C177, C179,
C313, C314, C318, C319
2CC1-16-C0G500-43
0J
R flake multi-layer
capacitor
1608, 43P±5%, 50V, C0G 1 C221
2CC1-16-C0G500-47
0J
R flake multi-layer
capacitor
1608, 47P±5%, 50V, C0G 2 C220, C256
2CC1-16-C0G500-47
1J
R flake multi-layer
capacitor
1608, 470P±5%, 50V, C0G 4 C105, C107, C108, C127
2CC1-16-C0G500-4R
0C
R flake multi-layer
capacitor
1608, 4P±0.25P, 50V, C0G 3 C128, C168, C170
2CC1-16-C0G500-5R
0B
flake multi-layer
capacitor
1608, 5P±0.1P, 50V, C0G 4 C130, C163, C164, C165
2CC1-16-C0G500-62
0J
flake multi-layer
capacitor
1608, 62P±5%, 50V, C0G 4 C225, C232, C233, C257
2CC1-16-C0G500-6R
0C
R flake multi-layer
capacitor
1608, 6P±0.25P , 50V, C0G 5 C155, C156, C183, C231, C235
2CC1-16-C0G500-82
0J
R flake multi-layer
capacitor
1608, 82P±5%, 50V, C0G 4 C136, C181, C222, C226
2CC1-16-C0G500-8R
0C
R flake multi-layer
capacitor
1608, 8P±0.25P, 50V, C0G 1 C176
2CC1-16-C0G500-9R
0C
R flake multi-layer
capacitor
1608, 9P±0.25P, 50V, C0G 1 C137
2CC1-16-X7R500-10
3K
R flake multi-layer
capacitor
1608, 10nF±10%, 50V, X7R 29
C101, C103, C116, C118, C122, C125,
C139, C141, C143, C145, C147, C152,
C154, C245, C253, C290, C292, C296,
C298, C326, C335, C343, C400, C401,
C402, C404, C406, C407, C408
2CC1-16-X7R500-33 flake multi-layer 1608, 3300P±10%, 50V, X7R 1 C336
62
