Kirisun DR600 Service Manual

DR600 Service Manual
2K
capacitor
2CC1-16-X7R500-33
3K
R flake multi-layer
capacitor
1608, 33nF±10%, 50V, X7R 1 C327
2CC1-16-Y5V160-10
4Z
flake multi-layer
capacitor
1608, 100nF+80%/-20%, 16V, Y5V 19
C110, C112, C114, C158, C159, C162,
C185, C187, C195, C196, C209, C213,
C215, C217, C227, C229, C238, C241,
C243
2CC1-16-Y5V500-47
4Z
flake multi-layer
capacitor
1608, 470nF+80%/-20%, 50V, Y5V 1 R344
2CE1-VS250-101M0
607D
Patch aluminum
electrolytic capacitor
SMD-6.3x7.7mm, 100uF/25V 1 C403
2CT1-TS32-100-2R2
M
R patch tantalum
capacitor
3216, 2.2μF±20%, 10V, TS series (level A) 1 C178
2CT1-TS32-160-100
M
R patch tantalum
capacitor
3216, 10μF±20%, 16V, TS series (level A) 22
C100, C104, C115, C120, C121, C126,
C192, C252, C254, C282, C283, C284,
C285, C286, C287, C288, C293, C294,
C299, C328, C333, C405
2CT1-TS32-350-R10
M
R patch tantalum
capacitor
3216, 0.1μF±20%, 35V, TS series (level A) 1 C172
2CT1-TS32-350-R33
M
R patch tantalum
capacitor
3216, 0.33μF±20%, 35V, TS series (level A) 1 C173
2CT1-TS32-6R3-150
M
R patch tantalum
capacitor
3216, 15μF±20%, 6.3V, TS series (level A) 1 C109
2LL1-16-R82K
Laminated inductor
1608, 0.82uH±10%(MLF1608DR82K TA00)
2
L105, L117
2LW1-16UC-120G Patch winding inductor
1608, 12nH±2%, ceramic core
(C1608CB-12NG)
1 L205
2LW1-16UC-180G Patch winding inductor
1608, 18nH±2%, ceramic core
(C1608CB-18NG)
2 L113, C237
2LW1-16UC-R33G Patch winding inductor 1608, 330nH±2%(C1608BR33G), pb-free 6 L103, L104, L111, L115, L116, L120
2LW1-20UC-102J Patch winding inductor
2012, 1μH±5%, ceramic core
(C2012C-1R0J)
1 L214
63
