Kirisun DR600 Service Manual

DR600 Service Manual
2LW1-20UC-120GM Patch winding inductor
ceramic core LQW2UAS12NG00 ;,
12nH±2%
1 L119
2LW1-20UC-180J R Patch winding inductor
2012, 18nH±5%, ceramic core
(C2012C-18NJ)
2 L209, L210
2LW1-20UC-331J Patch winding inductor
2012, 330nH±5%, ceramic core (high
frequency)
2 L106, L118
2LW1-20UC-8R2J Patch winding inductor
2012, 8.2nH±5%, ceramic core
(C2012C-8N2J)
1 L107
2LW1-25UC-103J R Patch winding inductor
2520, 10μH±5%, ceramic core
(FLM2520-100J)
1 L122
2RE1-16-1000 Patch precision resistor 1608, 100Ω±1% 9
R105, R106, R113, R115, R117, R119,
R120, R121, R128
2RE1-16-1001
Patch precision resistor
1608, 1K±1%
2
R134, R135
2RE1-16-1200 Patch precision resistor 1608, 120Ω±1% 2 R108, R129
2RE1-16-1801 Patch precision resistor 1608, 1.8K±1% 1 C339
2RE1-16-47R0
Patch precision resistor
1608, 47Ω±1%
1
R124
2RE1-16-8201
R Patch precision
resistor
1608, 8.2K±1% 2 R342, R403
2RS1-16-000O R Flake resistor 1608, 0Ω 23
R122, R123, R125, R130, R131, R137,
R138, C191, R210, L211, R313, R314,
R315, R316, R319, R320, R325, R326,
R334, R335, R346, R348, R350
2RS1-16-103J R Flake resistor 1608, 10K±5% 9
R114, R132, R133, R140, R141, R142,
R143, R144, R145
2RS1-16-104J R Flake resistor 1608, 100K±5% 6 R100, R103, R107, R111, R118, R127
2RS1-16-123J R Flake resistor 1608, 12K±5% 2 R337, R343
2RS1-16-124J
R Flake resistor
1608, 120K±5%
2
R339, R341
2RS1-16-220J R Flake resistor 1608, 22Ω±5% 1 R218
2RS1-16-221J R Flake resistor 1608, 220Ω±5% 2 R211, R212
2RS1-16-270J R Flake resistor 1608, 27Ω±5% 1 R209
2RS1-16-302J
Flake resistor
1608, 3K±5%
2
R104, R116
64
