DR600 Service Manual
2RS1-16-472J
R Flake resistor
1608, 4.7K±5%
2
R101, R109
2RS1-16-473J R Flake resistor 1608, 47K±5% 5 R110, R220, R345, R400, R401
2RS1-16-511J Flake resistor 1608, 510Ω±5% 1 R219
2RS1-16-563J R Flake resistor 1608, 56K±5% 1 R207
2RS1-16-682J
R Flake resistor
1608, 6.8K±5%
2
R102, R112
2RS1-20-000O R Flake resistor 2012, 0Ω 2 L212, L213
5FE1-BLM11A601S
R patch EMI suppression
filter
1608,
BLM11A601S/BLM18AG601S(0138-05)
28
L100, L101, L102, L108, L109, L110,
L112, L114, L121, L123, L202, L207,
L300, R301, L301, R302, R303, R304,
R305, R306, R307, R308, R309, R310,
R311, R312, R329, R351
5FE1-BLM21P300S
R patch EMI suppression
filter
2012,
BLM21P300S/BLM21PG300S(0149-05)
1 L400
5FQ1-LFCN-400 Low pass filter
LFCN-400, 8.5W, DC to 400MHz, FV120,
Mini-Circuits
1 U402
5OT1-12R8-CEC3-05
03
R patch temperature
compensated crystal
oscillator
NT5032SA/NT5032SC, 12.8MHz±2.5PPm,
5.0*3.2*1.6mm
1 X100
6PM7-4067-HTB DR650-02Tx board
DR650-DVC0-TXBORAD-20130319.PCB,
1.6MM thick, FR-4, 70X194M, 4 layers
1
2RE1-16-2200 Patch precision resistor 1608, 220Ω±1% 1 R126
3CB3-A2548WV-2X1
0P
Board-to-board
connector
2*10 socket, spacing 2.54mm,
33.02X9X9.1mm, black, manufacturer:JOINT
TECH
1 J300
3CR7-SMA-50KWE-2 RF coaxial connector
SMA-50KWE-2, 5PIN plug-in unit, 90
degrees, 23mm long.pitch:2.54mm
1 J200
