Kirisun DR600 Service Manual

DR600 Service Manual
2CC1-16-C0G500-16
0J
R flake multi-layer
capacitor
1608, 16P±5%, 50V, C0G 1 C117
2CC1-32-C0G102-2R
0J
R flake multi-layer
capacitor
3216, 2P±0.25P, 1000V, C0G 3 C118, C132, C135
2CC1-32-C0G101-10
2J
flake multi-layer
capacitor
3216, 1000P±5%, 100V, C0G,
GRM3195C2A102JA01D
3 C125, C126, C160
2CC1-16-C0G500-2R
0B
flake multi-layer
capacitor
1608, 2P±0.1P, 50V, C0G 2 C127, C130
2CC1-32-C0G102-4R
0J
R flake multi-layer
capacitor
3216, 4P±0.25P, 1000V, C0G 1 C133
2CC1-32-C0G102-5R
0J
R flake multi-layer
capacitor
3216, 5P±5%, 1000V, C0G 1 C134
2CC1-16-C0G500-47
1J
R flake multi-layer
capacitor
1608, 470P±5%, 50V, C0G 8
C141, C145, C147, C152, C154, C155,
C156, C157
2CC1-16-C0G500-5R
0C
R flake multi-layer
capacitor
1608, 5P±0.25P, 50V, C0G 2 C144, C146
2CC1-16-C0G500-10
2J
flake multi-layer
capacitor
1608, 1000P±5%, 50V, C0G 1 C148
2CC1-16-C0G500-22
1J
R flake multi-layer
capacitor
1608, 220P±5%, 50V, C0G 1 C149
2CC1-16-X7R500-10
3K
R flake multi-layer
capacitor
1608, 10nF±10%, 50V, X7R 10
C153, C162, C165, C200, C201, C202,
C204, C206, C207, C208
2CT1-TS32-100-220
M
Patch tantalum capacitor 3216, 22μF±20%, 10V, TS series (level A) 1 C205
1DR1-MM3Z15VT1G
Patch electrostatic-proof
zener diode
MM3Z2V4T1 series, 15V, W=1.2mm,
L=2.5mm, H=1.0mm, pb-free
3 D100, D101, D200
1DZ1-HZU5ALL
R patch voltage
stabilization diode
(production halts)
HZU5ALL, 2012, 5V 1 D102
1DS1-RB706F-40 R patch switch diode Schottky tube RB706F-40, SOT-323 2 D103, D104
67
