Kirisun DR600 Service Manual

DR600 Service Manual
1DS1-HVC131
R patch switch diode
(production halts)
HVC131(P1), 1608 1 D202
1IL1-NJM2904V R patch linear IC
Dual calculation amplification NJM2904V,
TSSOP-8
1 IC100
1IM1-AT24C08CN-S
H
E R analog commercial
portable and mobile
patch memerizor IC
EEPROPM, AT24C08CN-SH(8-SOIC) 1 IC6005
5FE1-BLM41P600SP
T
R patch EMI suppression
filter
EMI, FILTER, SMT, BLM41P600SPT,
1206, pb-free
3 L100, L101, L102
5FE1-BLM11A601S
R patch EMI suppression
filter
1608,
BLM11A601S/BLM18AG601S(0138-05)
11
L103, L110, R300, R301, R302, R303,
R304, R305, R308, R309, R310
2LW1-20UC-330GA
R patch winding inductor
2012, 33nH±2%(C2012C-33NG)
1
L104
2LL1-16-8N2D Laminated inductor 1608, 8.2nH±0.5nH(MLG1608B8N2DT) 2 L105, L106
2LH1-R903R0-L02-0
3
R patch air core inductor
wire diameter φ0.9, internal diameterφ3.0,
1.5 circles, back-roll, , pb-free
3 L107, L108, L109
2RS1-16-471J R flake resistor 1608, 470Ω±5% 1 L111
2LH1-R903R0-L11-0
5
R patch air core inductor
wire diameterφ0.9, internal diameterφ3.0, 11
circles, pin height 0.5mm, back-roll
1 L112
2LL1-16-47NJ R Laminated inductor 1608, 47nH±5%(MLG1608B47NJ) 2 L114, L115
5FE1-BLM21P300S
R patch EMI suppression
filte
2012,
BLM21P300S/BLM21PG300S(0149-05)
1 L200
1TT1-FMMT717TA
R patch triode
FMMT717A, PNP, SOT23
2
Q100, Q103
1TT1-DTC114YE patch triode Digital triode DTC114YE-SMD 3 Q101, Q104, Q200
1TT1-2SC3357 R patch triode 2SC3357(RE), SOT89(NEC) 1 Q102
2RS1-16-473J R Flake resistor 1608, 47K±5% 9
R100, R118, R133, R200, R201, R6042,
R6043, R6052, R6053
2RS1-16-561J R Flake resistor 1608, 560Ω±5% 2 R101, R119
2RE1-16-8201
R patch precision
resistor
1608, 8.2K±1% 2 R102, R203
2RS1-16-820J Flake resistor 1608, 82Ω±5% 2 R105, R115
2RE1-16-1501 R patch precision 1608, 1.5K±1% 1 R106
68
