Kirisun DR600 Service Manual

DR600 Service Manual
resistor
2RS1-16-270J R Flake resistor 1608, 27Ω±5% 2 R108, R109
2RS1-16-221J R Flake resistor 1608, 220Ω±5% 4 R110, R111, R112, R114
2RS1-16-000O R Flake resistor 1608, 0Ω 8
R130, R141, R113, R128, R143, R146,
R147, R311
2RS1-16-222J R Flake resistor 1608, 2.2K±5% 1 R120
2RS1-16-103J R Flake resistor 1608, 10K±5% 7
R121, R122, R123, R124, R125, R129,
R307
2RS1-16-202J R Flake resistor 1608, 2K±5% 1 R126
2RS1-16-104J R Flake resistor 1608, 100K±5% 1 R127
2RS1-16-821J
R Flake resistor
1608, 820Ω±5%
1
R131
2RS1-16-510J R Flake resistor 1608, 51Ω±5% 1 R134
2RS1-16-512J Flake resistor 1608, 5.1K±5% 3 R137, R138, R135
2RE1-16-1000 patch precision resistor 1608, 100Ω±1% 1 R142
1IS1-XC6701D332P
R
3.3VLDO
28V high input voltage, fast speed and low
consumption LDO with fast speed and low
consumption, 3.3V output, SOT-89
1 U102
1IS1-LM2941S Patch specialized IC
LM2941S/TO-236, 5PIN, low dropout voltage
regulator, pb-free
1 U200
6PM7-4071-HPA
SEPURA power
amplification board
PCB
power amplification board PCB, four layers,
FR4, 58.24X70,
RFAMPLIFIER-20130719.PCB, pb-free
1
2CC1-32-C0G501-1R
0C
Flake multi-layer
capacitor
3216, 1P±0.25%, 500V, C0G,
GRM31M5C2H1R0CY21B
1 C119
1DR1-XBS053V15R-
1G
Patch schottky diode
XBS053V15R-1G, SOD-523, VR=20V,
VF=0.40V, manufatured by TOREX, pb-free
1 D201
2CC1-32-C0G500-10
2J
Flake multi-layer
capacitor
3216, 1000P±5%, 50V, C0G 1 L113
69
