Kirisun DR600 Service Manual

DR600 Service Manual
1IS1-XC6209F502PR
SMD voltage regulator
IC
XC6209F502PR, SOT-89-5, 5.0V
6
Q4003, Q1002, Q1004, Q3000, Q3003,
Q3005
1TC1-UMC4 R SMD multiunit tube UMC4, NPN/PNP multiunit tube 2 U1000, U3000
1TF1-2SJ243
R SMD FET(off
production)
2SJ243-SMD
2
Q1008, Q1010
1TT1-2SC3356-R24 R SMD triode (off
production)
2SC3356-R24, SOT23, NPN 7 Q1009, Q1011, Q2002, Q3001, Q3002,
Q3004, Q4000
1TT1-2SC4617-R R SMD triode 2SC4617-R(BR), EMT3 2 Q1001, Q1005
1TT1-2SC5006 SMD triode(off
production)
2SC5006 1 Q1007
1TT1-DTC114YE SMD triode Digital triode DTC114YE-SMD 2 Q4001, Q5000
2CC1-16-C0G500-10
0D
R flake multi-layer
capacitor
1608, 10P±0.5P, 50V, C0G 6 C1085, C1086, C3013, C3015, C3023,
C3025
2CC1-16-C0G500-9R
0C
R flake multi-layer
capacitor
1608, 9P±0.25P, 50V, C0G 2 C1108, C1068
2CC1-16-C0G500-27
0J
R flake multi-layer
capacitor
1608, 27P±5%, 50V, C0G
2
C1079, C4019
2CC1-16-C0G500-43
0J
R flake multi-layer
capacitor
1608, 43P±5%, 50V, C0G 2 C1102, C1118
2CC1-16-C0G500-4R
0B
flake multi-layer
capacitor
1608, 4P±0.1P, 50V, C0G 3 C1109, C3001, C2019
2CC1-16-C0G500-10
1J
R flake multi-layer
capacitor
1608, 100P±5%, 50V, C0G 58 C1001, C1004, C1010, C1015, C1018,
C1021, C1024, C1026, C1029, C1035,
C1037, C1039, C1042, C1044, C1046,
C1049, C1051, C1053, C1059, C1063,
C1064, C1104, C1105, C1112, C1119,
C2008, C2010, C2012, C2017, C3027,
C3031, C3040, C3042, C3047, C3082,
C3091, C3095, C3110, C1034, C1056
2CC1-16-C0G500-12
0J
R flake multi-layer
capacitor
1608, 12P±5%, 50V, C0G 3 C3106, C2030, C2032
71

Kirisun DR600 Specifications

General

Brand	Kirisun
Model	DR600
Category	Repeater
Language	English
