Kirisun DR600 Service Manual

DR600 Service Manual
2CC1-16-C0G500-12
1J
R flake multi-layer
capacitor
1608, 120P±5%, 50V, C0G
2
C2021, C2023
2CC1-16-C0G500-15
0J
R flake multi-layer
capacitor
1608, 15P±5%, 50V, C0G 7 C3064, C3072, C3107, C3005, C3006,
C3010, C3011
2CC1-16-C0G500-18
0J
R flake multi-layer
capacitor
1608, 18P±5%, 50V, C0G 2 C1094, C3104
2CC1-16-C0G500-1R
0B
flake multi-layer
capacitor
1608, 1P±0.1P, 50V, C0G 8 C1103, C1117, C6020, C6026, C6036,
C6041, C6057, C6063
2CC1-16-C0G500-20
0J
R flake multi-layer
capacitor
1608, 20P±5%, 50V, C0G 2 C1114, C1115
2CC1-16-C0G500-22
0J
R flake multi-layer
capacitor
1608, 22P±5%, 50V, C0G 4 C3050, C3021, C3022, C2031
2CC1-16-C0G500-22
1J
R flake multi-layer
capacitor
1608, 220P±5%, 50V, C0G 4 C3052, C3057, C3084, C3088
2CC1-16-C0G500-24
0J
R flake multi-layer
capacitor
1608, 24P±5%, 50V, C0G 3 C1100, C1054, C1055
2CC1-16-C0G500-30
0J
R flake multi-layer
capacitor
1608, 30P±5%, 50V, C0G 2 C1095, C1096
2CC1-16-C0G500-33
0J
flake multi-layer
capacitor
1608, 33P±5%, 50V, C0G 2 C3019, C3020
2CC1-16-C0G500-47
0J
R flake multi-layer
capacitor
1608, 47P±5%, 50V, C0G 45 C1084, C1099, C2024, C6021, C6022,
C6023, C6024, C6025, C6027, C6028,
C6029, C6030, C6031, C6032, C6033,
C6034, C6035, C6037, C6038, C6039,
C6040, C6042, C6043, C6044, C6045,
C6046, C6047, C6048, C6049, C6050,
C6051, C6052, C6053, C6054, C6055,
C6056, C6058, C6059
2CC1-16-C0G500-47
1J
R flake multi-layer
capacitor
1608, 470P±5%, 50V, C0G 16 C3070, C1006, C1007, C1008, C1067,
C1089, C1090, R3037, C3003, C3004,
C3007, C3009, C3012, C1012, C1032,
72
