Kirisun DR600 Service Manual

DR600 Service Manual
2CC1-16-X7R500-27
1K
R flake multi-layer
capacitor
1608, 270P±10%, 50V, X7R
2
C1087, C1088
2CC1-16-X7R500-33
1K
flake multi-layer
capacitor
1608, 330P±10%, 50V, X7R 5 C3114, C3054, C3068, C3108, C3115
2CC1-16-Y5V160-10
4Z
flake multi-layer
capacitor
1608, 100nF+80%/-20%, 16V, Y5V 24 C1065, C1078, C1081, C1083, C1106,
C1113, C2009, C2011, C2013, C2014,
C2038, C3041, C3045, C3049, C3071,
C3079, C3081, C3086, C3087, C3089,
C3090, C3092, C3101, C3103
2CC1-16-Y5V250-10
5Z
flake multi-layer
capacitor
1608, 1μF+80%/-20%, 25V, Y5V
3
R6004, C6014, C6015
2CE1-VS250-101M0
607D
SMD aluminum
electrolytic capacitor
SMD-6.3x7.7mm, 100uF/25V 1 C5003
2CT1-TS32-100-220
M
SMD tantalum capacitor 3216, 22μF±20%, 10V, TS series(A level) 1 C5005
2CT1-TS32-100-2R2
M
R SMD tantalum
capacitor
3216, 2.2μF±20%, 10V, TS series(A level)
1
C1075
2CT1-TS32-160-100
M
R SMD tantalum
capacitor
3216, 10μF±20%, 16V, TS series(A level) 29 C4029, C4024, C4040, C4045, C4047,
C4052, C6007, C1000, C1005, C1014,
C1019, C1020, C1025, C1030, C1031,
C6002, C6008, C6011, C3029, C3030,
C3046, C3067, C3094, C3097, C3109,
C3112, C3113, C1057, C1058
2CT1-TS32-350-R10
M
R SMD tantalum
capacitor
3216, 0.1μF±20%, 35V, TS series(A level) 2 C1069, C3100
2CT1-TS32-350-R33
M
R SMD tantalum
capacitor
3216, 0.33μF±20%, 35V, TS series(A level) 1 C1070
2CT1-TS32-6R3-150
M
R SMD tantalum
capacitor
3216, 15μF±20%, 6.3V, TS series(A level) 3 C1009, C1011, C1013
2LL1-16-1R0K
R laminated inductor
1608, 1μH±10%(MLF1608A1R0K)
2
L1025, L3013
2LL1-16-3R3K R laminated inductor 1608, 3.3μH±10%(MLF1608A3R3K TA00) 3 L4004, L1007, L1029
74
