Kirisun DR600 Service Manual

DR600 Service Manual
2LW1-16UC-181J
SMD wire winding
inductor
1608, 180nH±5%, ceramic
core(C1608CB-R18J)
1
L2006
2LW1-16UC-330J R SMD wire winding
inductor
1608, 33nH±5%, ceramic core
(C1608CB-33NJ)
1 L1013
2LW1-20UC-470J R SMD wire winding
inductor
2012, 47nH±5%, ceramic core
(C2012C-47NJ)
4 L3004, L3000, L3001, L3002
2LW1-16UC-271G SMD wire winding
inductor
1608, 270nH±2%, ceramic core
(C1608CB-R27G-RF)
2 L3016, L3021
2LW1-16UC-R33G SMD wire winding
inductor
1608, 330nH±2%(C1608BR33G), pb-free 10 L1005, L1006, L1011, L1015, L1023,
L1024, L1026, L1027, L1028, L1030
2LW1-20UC-102J SMD wire winding
inductor
2012, 1μH±5%, ceramic core
(C2012C-1R0J)
3 L2004, L3007, L3024
2LW1-20UC-330J R SMD wire winding
inductor
2012, 33nH±5%, ceramic core
(C2012C-33NJ)
2 L2009, L2010
2LW1-20UC-330GC SMD wire winding
inductor
2012, 33nH±2%, 500mA,
LQW2BAS33NG00, SMD wire winding
inductor, muRata brand
1 L1016
2LW1-20UC-390GB SMD wire winding
inductor
2012, 39nH±2%, 500mA,
LQW2BAS39NG00, SMD wire winding
inductor, muRata brand
1 L1017
2LW1-20UC-331J SMD wire winding
inductor
2012, 330nH±5%, ceramic core (high
frequency)
3 L1019, L1020, L4001
2LW1-25UC-103J R SMD wire winding
inductor
2520, 10μH±5%, ceramic core
(FLM2520-100J)
4 L1022, L3005, L4002, L4003
2RE1-16-1000 SMD precision resistor 1608, 100Ω±1% 8 R1008, R1009, R1010, R1013, R1014,
R1016, R1022, R1024
2RE1-16-1200 SMD precision resistor 1608, 120Ω±1% 7 R1005, R1021, R1025, C4009,
C4010, R3002, R3003
2RE1-16-3301 SMD precision resistor 1608, 3.3K±1% 2 R3029, C3083
2RE1-16-47R0 SMD precision resistor 1608, 47Ω±1% 2 R1019, R3000
2RS1-16-000O R flake resistor 1608, 0Ω 19 R1017, R1018, R1029, R2010, L2012,
75
