Kirisun DR600 Service Manual

DR600 Service Manual
C3039, L3015, R3018, R3027, R3028,
R3031, R3038, R3042, R6012, R6013,
R1020, R6040, R6041, R4003
2RS1-16-102J R flake resistor 1608, 1K±5% 6 R1023, R1028, R1042, R3036, R4004,
R4009
2RS1-16-103J
R flake resistor
1608, 10K±5%
19
R1035, R1036, R1037, R1007, R1011,
R1030, R1031, R1032, R1033, R1034,
R1039, R1040, R3017, R6007, R6009,
R1041, R4002, R4007, R4008
2RS1-16-104J
R flake resistor
1608, 100K±5%
13
R3005, R3006, R3007, R3008, R3009,
R3010, R3011, R3012, R3013, R3014,
R3015, R3016, R4006
2RS1-16-124J R flake resistor 1608, 120K±5% 1 R1026
2RS1-16-153J R flake resistor 1608, 15K±5% 1 R6005
2RS1-16-182J R flake resistor 1608, 1.8K±5% 2 R3024, R3026
2RS1-16-184J
R flake resistor
1608, 180K±5%
1
R3041
2RS1-16-220J R flake resistor 1608, 22Ω±5% 1 R2018
2RS1-16-221J R flake resistor 1608, 220Ω±5% 2 R2011, R2012
2RS1-16-223J R flake resistor 1608, 22K±5% 4 R3039, R3040, R3045, R3046
2RS1-16-270J
R flake resistor
1608, 27Ω±5%
1
R2009
2RS1-16-273J
R flake resistor
1608, 27K±5%
2
R6008, R6010
2RS1-16-362J R flake resistor 1608, 3.6K±5% 1 R6011
2RS1-16-363J R flake resistor 1608, 36K±5% 2 R3030, R3032
2RS1-16-364J
flake resistor
1608, 360K±5%
1
R3049
2RS1-16-392J R flake resistor 1608, 3.9K±5% 3 R1002, R1015, R3043
2RS1-16-472J R flake resistor 1608, 4.7K±5% 8 R1006, R3033, R1000, R1001, R3019,
R3021, R3044, R3047
2RS1-16-473J R flake resistor 1608, 47K±5% 8 R3023, R3025, R5000, R5001, R6042,
R6043, R6052, R6053
2RS1-16-513J
R flake resistor
1608, 51K±5%
1
R6001
2RS1-16-560J
R flake resistor
1608, 56Ω±5%
2
R3052, L4000
76
