Kirisun DR600 Service Manual

DR600 Service Manual
2RS1-16-682J
R flake resistor
1608, 6.8K±5%
2
R102, R112
2RS1-20-000O R flake resistor 2012, 0Ω 2 L212, L213
5FE1-BLM11A601S R SMD EMI suppression
filter
1608,
BLM11A601S/BLM18AG601S(0138-05)
28 L100, L101, L102, L108, L109, L110,
L112, L114, L121, L123, L202, L207,
L300, R301, L301, R302, R303, R304,
R305, R306, R307, R308, R309, R310,
R311, R312, R329, R351
5FE1-BLM21P300S
R SMD EMI suppression
filter
2012,
BLM21P300S/BLM21PG300S(0149-05)
1
L400
5OT1-12R8-ACL4-32
25
SMD temperature
compensated crystal
oscillator
KDS, 12.8MHz±1.5ppm, Vc=1.5±1V, range:
±35ppm, -40℃～85, 3225
1 X100
6PD7-1861-HLC
Crystal adaptor board
Thickness 0.6mm, FR4 material
1
6PM7-4067-HTB DR650-02 TX board DR650-DVC0-TXBORAD-20130319.PCB,
thickness 1.6MM, FR-4, 70X194M, 4 layers
1
2CC1-16-Y5V160-47
4Z
R flake multi-layer
capacitor
1608, 470nF+80%/-20%, 16V, Y5V
1
R344
2RS1-16-183J R flake resistor 1608, 18K±5% 1 C339
2CC1-16-C0G500-27
0J
R flake multi-layer
capacitor
1608, 27P±5%, 50V, C0G
1
C137
2RS1-32-000O R flake resistor 3216, 0Ω±5% 1 U402
2RS1-16-222J R flake resistor 1608, 2.2K±5% 1 R138
2CC1-16-X7R500-20
2K
flake multi-layer
capacitor
1608, 2000P±10%, 50V, X7R 1 C198
2RS1-16-820J flake resistor 1608, 82Ω±5% 1 R126
2CC1-16-C0G500-30
0J
R flake multi-layer
capacitor
1608, 30P±5%, 50V, C0G 2 C128, C168
2CC1-16-C0G500-9R
0C
R flake multi-layer
capacitor
1608, 9P±0.25P, 50V, C0G 1 C134
0SS2-4095-HTA STR-V TX board plug-in
unit
STR-VTX board plug-in unit,pb-free 1 IC102, IC104, IC105, IC302
84
