DR600 Service Manual

3CB3-A2548WV-2X1

Plug-in unit

board-to-board

connector

2*10 socket(male), interval 2.54mm,

33.02X9X9.1mm, black,

J300

3CR7-SMA-50KWE-2 RF coaxial connector SMA-50KWE-2, 5PIN plug-in unit, 90

degrees, length 23mm.pitch:2.54mm,

1 J200

Table 5 136-174 Part List(TX Module Section)

Part No. Part Name Specification Quantity Location

3FW1-42932-302320 R SMD fuse 429003/433003/466003,3216,3A/32V 1 CB400

1DR1-MM3Z12VT1G Anti-static zener diode MM3Z12VT1G, 3V, SOD323, pb-free 1 D400

1DS1-HSC277 R SMD switchdiode(off

production)

HSC277,1608 1 D100

1DV1-1SV278 R SMD varactor diode 1SV278(T1) 2 D105,D110

1DV1-1SV305 R SMD varactor diode 1SV305 8 D101,D102,D103,D104,D106,D107,D10

8,D109

1IS1-LM2941S SMD specialized IC LM2941S/TO-236, 5PIN, low dropout voltage

regulator, pb-free

1 U400

1IS1-SKY72310 PLL chip SKY72310,24 pin QFN 4mmX4mm

pb-free(QFN-N24_B4x4-P0_5), pb-free

1 IC100

1IS1-PGA103 Broad band low noise

amplifier

PGA-103+,0.05to4GHz,SOT-89,PACKAGE,

Mini-Circuits brand,RoHS

1 IC306

1IS1-TC75S51F SMD single operational

amplifier IC

TC75S51F,SSOP5-P-0.95 2 IC300,IC301

1IS1-XC6209F302PR SMD voltage regulator

XC6209F302PR, SOT-89-5, 3.0V 1 IC101

1IS1-XC6209F332PR SMD voltage regulator

XC6209F332PR, SOT-89-5, 3.3V 1 IC103
