DR600 Service Manual
217,C227,C229,C238,C241,C243
2CE1-VS250-101M0
607D
SMD aluminum
electrolytic capacitor
SMD-6.3x7.7mm, 100uF/25V 1 C403
2CT1-TS32-160-4R7
M
R SMD tantalum
capacitor
3216,4.7μF±20%,16V,TS series (A level)
1
C178
2CT1-TS32-160-100
M
R SMD tantalum
capacitor
3216,10μF±20%,16V,TS series (A level) 21 C100,C104,C115,C120,C121,C126,C25
2,C254,C282,C283,C284,C285,C286,C
287,C288,C293,C294,C299,C328,C333
,C405
2CT1-TS32-350-R10
M
R SMD tantalum
capacitor
3216,0.1μF±20%,35V,TS series (A level) 3 C172,C173,C174
2CC1-16-C0G500-24
0J
R flake multi-layer
capacitor
1608,24P±5%,50V,C0G 3 C176,C183,C132
2CT1-TS32-6R3-150
M
R SMD tantalum
capacitor
3216,15μF±20%,6.3V,TS series (A level)
1
C109
2LL1-16-3R3K R laminated inductor 1608,3.3μH±10%(MLF1608A3R3K TA00) 2 L105,L117
2LW1-16UC-181J SMD wire winding
inductor
1608,180nH±5%, ceramic core
(C1608CB-R18J)
1 L205
2LW1-16UC-560G SMD wire winding
inductor
1608,56nH±2%, ceramic core
(C1608CB-56NG)
1 L113
2LW1-16UC-R33G SMD wire winding
inductor
1608,330nH±2%(C1608BR33G), pb-free 6 L103,L104,L111,L115,L116,L120
2LW1-20UC-102J
SMD wire winding
inductor
2012,1μH±5%, ceramic core (C2012C-1R0J)
2
L214,L106
2LW1-20UC-470GB SMD wire winding
inductor
2012, 47nH±2%,
500mA,LQW2BAS47NG00 ,muRata brand
1 L119
2LW1-20UC-560JA R SMD wire winding
inductor
2012,56nH±5%, ceramic core
(C2012C-56NJ)
2 L209,L210
2LW1-20UC-221J R SMD wire winding
inductor
2012,220nH±5%, ceramic core
(LQN21AR22J/LQW2BHNR22J03L)
1 L118
2LW1-20UC-330GC SMD wire winding 2012, 33nH±2%, 1 L107
88
