Kirisun DR600 Service Manual

DR600 Service Manual
inductor
500mA,LQW2BAS33NG00, SMD wire
winding inductor,muRata brand
2LW1-25UC-103J R SMD wire winding
inductor
2520,10μH±5%, ceramic core
(FLM2520-100J)
1 L122
2RE1-16-1000 SMD precision resistor 1608,100Ω±1% 11 R129,R124,R105,R106,R113,R115,R11
7,R119,R120,R121,R128
2RE1-16-1001
SMD precision resistor
1608,1K±1%
2
R134,R135
2RE1-16-1200 SMD precision resistor 1608,120Ω±1% 1 R108
2RE1-16-8201 R SMD precision resistor 1608,8.2K±1% 2 R342,R403
2RS1-16-000O R flake resistor 1608,0Ω 21 C191,R131,R137,R335,R122,R123,R13
0,R210,L211,R325,R326,R334,R346,R
348,R319,R320,R350,R313,R314,R315
,R316
2RS1-16-103J R flake resistor 1608,10K±5% 9 R114,R132,R133,R140,R141,R142,R14
3,R144,R145
2RS1-16-104J R flake resistor 1608,100K±5% 6 R100,R103,R107,R111,R118,R127
2RS1-16-123J R flake resistor 1608,12K±5% 2 R343,R337
2RS1-16-124J
R flake resistor
1608,120K±5%
2
R339,R341
2RS1-16-220J R flake resistor 1608,22Ω±5% 1 R218
2RS1-16-221J R flake resistor 1608,220Ω±5% 2 R211,R212
2RS1-16-270J R flake resistor 1608,27Ω±5% 2 R209,R125
2RS1-16-302J
flake resistor
1608,3K±5%
2
R104,R116
2RS1-16-472J
R flake resistor
1608,4.7K±5%
2
R101,R109
2RS1-16-473J R flake resistor 1608,47K±5% 5 R345,R110,R220,R400,R401
2RS1-16-511J flake resistor 1608,510Ω±5% 1 R219
2RS1-16-563J
R flake resistor
1608,56K±5%
1
R207
2RS1-16-682J R flake resistor 1608,6.8K±5% 2 R102,R112
2RS1-20-000O R flake resistor 2012,0Ω 2 L212,L213
5FE1-BLM11A601S R SMD EMI suppression
filter
1608,BLM11A601S/BLM18AG601S(0138-05
)
28 L100,L101,L102,L108,L109,L110,L112,
L114,L121,L123,L202,L207,L300,R301,
89
