Kirisun DR600 Service Manual

DR600 Service Manual
L301,R302,R303,R304,R305,R306,R30
7,R308,R309,R310,R311,R312,R329,R
351
5FE1-BLM21P300S R SMD EMI suppression
filter
2012,BLM21P300S/BLM21PG300S(0149-0
5)
1 L400
5OT1-12R8-ACL4-32
25
SMD temperature
compensated crystal
oscillator
KDS,12.8MHz±1.5ppm,Vc=1.5±1V
range:±35ppm,-40℃～85,3225
1
X100
6PD7-1861-HLC Crystal adaptor board Thickness 0.6mm,FR4 material 1
6PM7-4067-HTB DR650-02 TX board DR650-DVC0-TXBORAD-20130319.PCB,
thickness1.6MM,FR-4,70X194M,4layers
1
2CC1-16-Y5V160-47
4Z
R flake multi-layer
capacitor
1608,470nF+80%/-20%,16V,Y5V 1 R344
2RS1-16-183J
R flake resistor
1608,18K±5%
1
C339
2CC1-16-C0G500-27
0J
R flake multi-layer
capacitor
1608,27P±5%,50V,C0G 1 C137
2RS1-32-000O R flake resistor 3216,0Ω±5% 1 U402
2RS1-16-222J R flake resistor 1608,2.2K±5% 1 R138
2CC1-16-X7R500-20
2K
flake multi-layer
capacitor
1608,2000P±10%,50V,X7R 1 C198
2RS1-16-820J
flake resistor
1608,82Ω±5%
1
R126
2CC1-16-C0G500-30
0J
R flake multi-layer
capacitor
1608,30P±5%,50V,C0G 2 C128,C168
2CC1-16-C0G500-9R
0C
R flake multi-layer
capacitor
1608,9P±0.25P,50V,C0G 1 C134
0SS2-4095-HTA STR-V TX board plug-in
unit
STR-V, pb-free 1 IC102,IC104,IC105,IC302
3CB3-A2548WV-2X1
0P
Plug-in board-to-board
connector
2*10 socket(male), interval
2.54mm,33.02X9X9.1mm,black
1 J300
3CR7-SMA-50KWE-2 RF coaxial connector SMA-50KWE-2, 5PIN plug-in unit, 90
degrees h:2.54mm
1 J200
90
