Kirisun DR600 Service Manual

DR600 Service Manual
Table 6 136-174 Part List(Power Amplification Module Section)
Part No. Part Name Specification Quantity Location
3FW1-42932-302320
R SMD fuse
429003/433003/466003,3216,3A/32V
1
CB300
2CE1-VS250-101M0
607D
SMD aluminum
electrolytic capacitor
SMD-6.3x7.7mm, 100uF/25V 3 C100,C105,C203
2CC1-16-C0G500-10
1J
R flake multi-layer
capacitor
1608,100P±5%,50V,C0G
37
C101,C103,C106,C108,C110,C112,C11
3,C114,C116,C121,C122,C123,C124,C
137,C139,C150,C161,C164,C167,C300
,C301,C302,C303,C304,C305,C306,C3
07,C308,C309,C310,C311,C312,C313,
C314,C315,C316,C317
2CC1-16-Y5V160-10
4Z
flake multi-layer
capacitor
1608,100nF+80%/-20%,16V,Y5V 10 C102,C104,C107,C109,C115,C129,C13
8,C140,C142,C143
2CT1-TS32-160-100
M
R SMD tantalum
capacitor
3216,10μF±20%,16V,TSseries (A level) 4 C111,C136,C163,C166
2CC1-16-C0G500-16
0J
R flake multi-layer
capacitor
1608,16P±5%,50V,C0G 1 C117
2CC1-32-C0G102-5R
0J
R flake multi-layer
capacitor
3216,5P±5%,1000V,C0G 1 C118
2CC1-32-C0G102-6R
0J
R flake multi-layer
capacitor
3216,6P±0.25P,1000V,C0G 1 C119
2CC1-32-C0G102-4R
0J
R flake multi-layer
capacitor
3216,4P±0.25P,1000V,C0G 1 C120
2CC1-32-C0G500-12
0J
flake multi-layer
capacitor
3216,12P±5%,50V,C0G 2 C132,C135
2CC1-32-C0G500-27
0J
flake multi-layer
capacitor
3216,27P±5%,50V,C0G 2 C133,C134
91
