Kirisun DR600 Service Manual

DR600 Service Manual
2CC1-16-C0G500-33
0J
flake multi-layer
capacitor
1608,33P±5%,50V,C0G
4
C144,C146,C168,C169
2CC1-32-C0G101-10
2J
flake multi-layer
capacitor
3216,1000P±5%,100V,C0G,GRM3195C2A1
02JA01D
3 C125,C126,C160
2CC1-16-C0G500-22
0J
R flake multi-layer
capacitor
1608,22P±5%,50V,C0G 4 C127,C128,C130,C131
2CC1-16-C0G500-47
1J
R flake multi-layer
capacitor
1608,470P±5%,50V,C0G 8 C141,C145,C147,C152,C154,C155,C15
6,C157
2CC1-16-C0G500-10
2J
flake multi-layer
capacitor
1608,1000P±5%,50V,C0G 1 C148
2CC1-16-C0G500-22
1J
R flake multi-layer
capacitor
1608,220P±5%,50V,C0G 1 C149
2CC1-16-X7R500-10
3K
R flake multi-layer
capacitor
1608,10nF±10%,50V,X7R 10 C153,C162,C165,C200,C201,C202,C20
4,C206,C207,C208
2CT1-TS32-100-220
M
SMD tantalum capacitor 3216,22μF±20%,10V,TSseries (A level) 1 C205
1DR1-MM3Z15VT1G SMD anti-static zener
diode
MM3Z2V4T1 TS series,
15V,W=1.2mm,L=2.5mm,H=1.0mm, pb-free
3 D100,D101,D200
1DZ1-HZU5ALL R SMD voltage regulator
diode (off production)
HZU5ALL,2012,5V 1 D102
1DS1-RB706F-40
R SMD switch diode
Schottky diode RB706F-40,SOT-323
2
D103,D104
1DR1-XBS053V15R-
1G
SMD schottky diode XBS053V15R-1G, SOD-523 package,
VR=20V,VF=0.40V, pb-free
2 D201,D202
1IL1-NJM2904V
R SMD linear IC
Double operational amplification
NJM2904V,TSSOP-8
1
IC100
5FE1-BLM41P600SP
T
R SMD EMI suppression
filter
EMI,FILTER, SMT,BLM41P600SPT,1206,
pb-free
3 L100,L101,L102
5FE1-BLM11A601S R SMD EMI suppression
filter
1608,BLM11A601S/BLM18AG601S(0138-05
)
11 L103,L110,R300,R301,R302,R303,R30
4,R305,R308,R309,R310
2LW1-20UC-68NG SMD wire winding
inductor
2012,68nH±2% wire winding
inductor,SAGAMI,C2012C-68NG
1 L104
92
