Kirisun DR600 Service Manual

DR600 Service Manual
2LH1-R903R0-L05-0
5
R SMD air core inductor
Wire diameter φ0.9, internal diameter φ3.0,5
circles, pin height 0.5mm, backward winding
3
L107,L108,L109
2RS1-16-471J R flake resistor 1608,470Ω±5% 1 L111
2LH1-R903R0-L11-0
5
R SMD air core inducto
Wire diameterφ0.9, internal diameterφ3.0,11
circles, pin height 0.5mm, backward winding
1
L112
2CC1-32-C0G500-10
2J
Flake multi-layer
capacitor
3216,1000P±5%,50V,C0G 1 L113
2LL1-16-47NJ R laminated inductor 1608,47nH±5%(MLG1608B47NJ) 4 L105,L106,L114,L115
5FE1-BLM21P300S R SMD EMI suppression
filter
2012,BLM21P300S/BLM21PG300S(0149-0
5)
1 L200
1TT1-FMMT717TA R SMD triode FMMT717A,PNP,SOT23 2 Q100,Q103
1TT1-DTC114YE SMD triode Digital triode DTC114YE-SMD 3 Q101,Q104,Q200
1TT1-2SC3357 R SMD triode (off
production)
2SC3357(RE),SOT89(NEC) 1 Q102
2RS1-16-473J R flake resistor 1608,47K±5% 9 R100,R118,R133,R200,R201,R6042,R6
043,R6052,R6053
2RS1-16-561J R flake resistor 1608,560Ω±5% 2 R101,R119
2RE1-16-8201 R SMD precision resistor 1608,8.2K±1% 2 R102,R203
2RS1-16-680J R flake resistor 1608,68Ω±5% 2 R105,R115
2RE1-16-1501
R SMD precision resistor
1608,1.5K±1%
1
R106
2RS1-16-270J R flake resistor 1608,27Ω±5% 2 R108,R109
2RS1-16-221J R flake resistor 1608,220Ω±5% 4 R110,R111,R112,R114
2RS1-16-000O R flake resistor 1608,0Ω 8 R130,
R113,R128,R141,R143,R146,R147,R31
1
2RS1-16-222J
R flake resistor
1608,2.2K±5%
1
R120
2RS1-16-103J R flake resistor 1608,10K±5% 6 R121,R123,R125,R129,R140,R307
2RS1-16-102J R flake resistor 1608,1K±5% 1 R124
2RS1-16-202J R flake resistor 1608,2K±5% 1 R126
2RS1-16-104J
R flake resistor
1608,100K±5%
1
R127
93
