2RS1-16-821J
R flake resistor
1608,820Ω±5%
1
R131
2RS1-16-510J R flake resistor 1608,51Ω±5% 1 R134
2RS1-16-512J flake resistor 1608,5.1K±5% 2 R137,R138
2RE1-16-1000 SMD precision resistor 1608,100Ω±1% 1 R142
1IS1-XC6701D332P
R
3.3VLDO 28V high voltage input, high-speed and low
consumption LDO, 3.3V output, package:
SOT-89
1 U102
1IS1-LM2941S SMD specialized IC LM2941S/TO-236, 5PIN, low dropout voltage
regulator, pb-free
1 U200
6PM7-4071-HPA
SEPURA power
amplification board
PCB
power amplification board PCB, four layers,
FR4,58.24X70,
RFAMPLIFIER-20130719.PCB, pb-free
1
2RS1-16-331J R flake resistor 1608,330Ω±5% 2 R135, R122
1IM1-AT24C08CN-S
H
E R SMD memorizer IC
for analog commercial
portable and mobile
EEPROPM,AT24C08CN-SH(8-SOIC) 1 IC6005
0SS2-4071-HPC STR-U power
amplification board
plug-in unit (130722)
STR-U power amplification board plug-in
unit, pb-free
1
3CB1-DC002 STR-U power
amplification board
power supply socket
DC-002, combination key, plastic pedestal+
two copper tablets, pb-free
1 J302
3CP3-LCP200 DM850 power supply
socket
LCP with plastic pedestal with ,2Pin,
nickel-plated brass pin, pb-free
1
7MBC-4073-01A-N STM-U power
connecting terminal
nickel-plated brass, pb-free 2
2RV3-22ZR-10D
R plug-in unit
piezoresistor
22ZR-10D
1
R306
3CR7-SMA-50KWE-2 RF coaxial connector SMA-50KWE-2, 5PIN plug-in unit, 90
degrees, length 23mm.pitch:2.54mm
1 J100
3CB3-A2548WV-2X0 Plug-in unit A2548WV-2X05P, male, 180 degrees, 1 J300
94
