Kirisun DR600 Service Manual

DR600 Service Manual
5P
board-to-board
connector
interval 2.54mm,20.32mmX9mmX9.1mm,
1IS3-DS18B20 Integrated IC Plug-in unit temperature sensor ,3.0V-5.5V
power supply, -55
℃
--125
℃
,TO-92
1 IC101
Table 7 Parts List (Baseband Mainboard)
Part No. Acccessory Names Quantity Location
3CB3-VH3096-2P DC power socket 1 J1
3CB3-S6160BK1
Board-to-board connector
2
J2
3CR7-SMA-50KE RF coaxial connectorw 3 J6, J7, J8
3CB3-A2548WV-2X05P Board-to-board connector 4 J5, J18, J19, J23
3CB3-A2548WV-2X13P Board-to-board connector 2 J9, J15
3CT3-KRJ003NL-8P
Crystal head RJ45 socket
1
J12
3CB3-A2548WV-2X10P Board-to-board connector 1 J17
3CL3-PH-20002 Bar connector 1 J20
3CL3-PH-25402A Bar connector 1 J27
2RV3-22ZR-10D
piezoresistor
1
R2
2CE3-GM350-102M1320 Aluminum electrolytic capacitor 2 C331, C522
3CL3-PH-20003 Bar connector 1 J21
2LI3-0911-331K I-shaped inductor 3 L12, L16, L17
7MBC-4073-04A-W
Large shield
4
P1, P2, P4, P5
7MBC-4073-05A-W Small shield 1 P3
6BLS-4814-03327U Patch button battery 1 BT2
2CC1-16-X7R500-103K Flake multi-layer capacitor 1 C1
2CC1-32-Y5V500-106Z Flake multi-layer capacitor 23
C2, C6, C21, C24, C29, C30, C31, C109, C175, C182, C183,
C226, C263, C277, C285, C286, , C251, C275, C288, , C506,
C507, C512, C513
95

Kirisun DR600 Specifications

General

Brand	Kirisun
Model	DR600
Category	Repeater
Language	English
