Kirisun TM840 Service Manual

TM840 Service Manual
7 7NRC-060104023-W M6x0.35 Nut, brass, M6xP0.35/Φ10.4x2.3，RE11(8P dedicated) 1
8 7MBS-4062-01A-W TM840 Keypad Metal Dome,SUS301#+PET film,φ5.00 Round metal
dome,11 bits
1
9 7MBS-4073-01B-W STM-U_LCD Bracket , Thickness 0.40mm stainless steel，natural color，
201402 change mould
1
10 4PC7-4038H-A LCD Screen, Imitate semipermeable, vertical screen across use, backlight,
high 42.7mm
1
11 6SS2-4073-HFB STM-U Mobile Panel Jacking 1
12 7STF-026060B-SZYB
-Z
M2.6*6 Cross Round Flat Head With convex tooth machine screws, Iron
and hard, Cross Round Flat Head, flush end, zinc plating-black
2
13 7MBR-4062-03A-W0 DM850 Handpiece waterproof Ring, 40 degree high elastic silicone，black 1
14 3WPT-S1938-01A Black and white twisted pair, With AC socket, 2.0*2P*70mm 1
15 6PF7-4073-HL2B STM-U Mobile FPC, STM-U-FPC-131218, Thickness 0.15mm, flexible
plate, 70*41mm, 2 layers
1
16 7MBR-4062-04A-W0 DM850 complete machine waterproof rin, 40 degree high elastic silicone，
black
1
17 7SMF-030060M-SZY
B-N
M3*6 Cross Round Flat Head machine screws, iron and hard, cross round
flat head, nickel plating machine teeth, metric coarse thread
4
18 7GGM-4073-03A-W STM-U_GPS Connector spongy cushion, EVA，black，12x7x3，single side
stamp gum
1
19 7MBR-4062-05A-W0 DM850 mainframe waterproof Ring, 40 degree high elastic silicone，black 1
20 7MBP-4073-03A-W0 STM-U Plastic Upper cover, PC 6485,black,Texture 1
21 7MHR-7069-08A-W0 O-Ring, D2.4X1.0MM 13
22 7SMF-030160M-MHY
B
M3*16 Round Head Plum Blossom Machine Screw, stainless steel, plum
blossom groove round head, passivation, metric machine teeth
9
23 7MBL-4062-02A-W-A DM850 Aluminum alloy cover (Drop rubber), Shield Rib face Drops of
conductive adhesive, high 0.50mm
1
24 3CR7-S4025-A2 DM890 GPS Antenna Head, SMA to ECT RF plug, wire length120mm 1
24
