25 7MBR-4062-10A-W0 DM850_DB26P waterproof rubber cover, 60 degree High elastic silicone，
blac
1
26 7MBF-4073-01A-Z0 STM-U_DB base waterproof cover, Thickness 1.00mm, stainless steel，
natural color
1
27 7NRC-063095021-G STM-U_GPS Antenna nut, brass，1/4-36/Φ9.5x2.1，gold plating 1
28 7MBR-4062-11A-W0 DM850_GPS Antenna head waterproof Rin, 40 degree High elastic
silicone，black
1
29 7MBS-4073-04A-W STM-U_GPS Antenna head waterproof washer, Thickness 0.40mm,
stainless steel，natural color
1
30 7MBL-4073-01A-W-A STM-U aluminum alloy Bracket (Drop rubber ), shield Rib face Drops of
conductive adhesive, 0.50mm high
1
31 7NRC-120150032-N STM-U Antenna nut, brass，M12xP0.75/
Φ15.0x3.2，vacuum white nickel plating
1
32 7MHC-4049-08A-W KH620D RF Board Top Shield Cover 1, sunlit copper , thickness0.2mm,
30.1*22.1
1
33 7MBR-4062-08A-W0 DM850 power socket waterproof cushion, 40 degree high elastic silicone，
black
1
34 7MBR-4062-09A-W0 DM850 Antenna Head Waterproof Ring, 40 degree high elastic silicone，
black
1
35 6SS2-4073-HMB STM-U Mobile mainboard jacking, STM-U Mobile mainboard jacking, with
GPS
1
35 6SS2-4073-HMC STM-U Mobile mainboard jacking, without GPS 1
36 7MBS-4073-06A-W STM-U Base Band Shield Cover, .20mmThicknessstainless steel，natural
color
1
37 7MBM-S4073-A STM-U EMI Gasket, EMI Gasket，50*18.5*1，single side stamp gum 1
38 7SAF-030080M-SZY
B-Z1
M3*8Cross Round Flat Head group Machine Screw, Iron and hard, Cross
Round Flat Head, zinc plating, with flat gasket and spring cushion
2
39 7MBS-4073-05A-W STM-U power module shield cover, 0.30mm Thickness, stainless steel，
natural color
1
25
