Kirisun TM840 Service Manual

TM840 Service Manual
40 1MR3-RA30H4047M power module, RA30H4047M (Low power，UHF) 1
40 1MR3-RA55H4047M UHF RF Amplifier IC, RA55H4047M (high power，UHF) 1
40 1MR3-RA30H1317M power module, RA30H1317M (low power，VHF) 1
40 1MR3-RA60H1317M power module, RA60H1317M (high power，VHF) 1
40 1MR3-RA30H3340 power module, RA30H3340 25W，350~390mHz） 1
40 1MR3-RA55H3340M power module, RA55H3340M（40W，350~390mHz） 1
41 7MBR-4062-06A-W0 DM850 aluminum alloy below cover waterproof Ring , 40 degree High
elastic silicone，black
1
42 7MBL-4062-03B-W DM850aluminium alloy below cover , aluminum alloy ADC12, silver, grind +
white washing + External surface stoving varnish +passivation
1
43 7SMF-030120M-MHY
B
M3*12 TORX round head Machine Screw, stainless steel, TORX round
head , passivation, Metric machine teeth
4
44 4SS7-3520-016-700 Speaker, Φ=35*58mm,H=20mm, impedance 16Ω, rated power 7W 1
45 7MBP-4062-05A-W0 DM850 keypad Bracket, Transparency ABS，colorless，polishing 1
46 7MBB-7220-01A-W0 PT8200M Speaker dustproof net , Import high density dust cloth，black 1
47 7MBR-4062-02A-W3 TM840 Alarm Button, 60 degree high elastic silicone，orange，silk-screen
+ PU oil
1
48 7MBR-4062-01A-W TM840 function button,P+R,atural color，spray laser mark 1
49 7GCM-4062-01A-W DM850_LCD Dustproof Cushion, PORON cushion，black，single side Stamp
gum
1
50 7MBR-4062-07A-W0 DM850 switch waterproof cushion, 40 degree high elastic silicone，black 1
51 7MBR-4025-02A-W0 DM890 Aviation plug Waterproof Ring, Silicone, 45 degree, orange 1
52 7GGP-S1943-J PT8200 Speaker cushion Ring,sponge, ring, black 1
53 7SMF-025050M-MHY
B-B
M2.5*5 Oblate Warbler Machine Screw, Iron and hard, warbler oblate
electrophoresis resistance to fall process
3
54 7MBP-4073-02A-W0 STM-U Rear Cover (spray lacquer), Material PC 6485, designated area 1
26

Kirisun TM840 Specifications

General

Brand	Kirisun
Model	TM840
Category	Radio
Language	English
