Kirisun TM840 Service Manual

TM840 Service Manual
130 2RS1-16-331J R Chip Resistance 1 L12
131 2RS1-16-220J R Chip Resistance 2 R350，R372
132 2RS1-16-391J Chip Resistance 5 R233，R206，R408，R360，R363
133 2RS1-16-224J R Chip Resistance 1 R247
134 2RS1-16-124J R Chip Resistance 1 R246
135 2RS1-16-824J Chip Resistance 5 R261，R262，R263，R3011，R3013
136 2RE1-16-2002 Chip Precision Resistance 1 R236
137 2RS1-10-330J R Chip Resistance 4 R282.R283.R285.R286
138 2RS1-16-151J R Chip Resistance 1 R339
139 2RS1-16-390J Chip Resistance 1 R326
140 2RS1-16-333J R Chip Resistance 2 R405，R36
141 2RS1-16-223J R Chip Resistance 1 R399
142 2RS1-16-563J R Chip Resistance 1 R398
143 2RS1-16-272J R Chip Resistance 1 R409
144 2RE1-16-1212 Chip Precision Resistance 1 R138
145 2RS1-16-560J R Chip Resistance 1 R310
146 2RT1-NTH5G16P40B473J R Chip thermistor 3 R573，R352，R401
147 2RV3-4032K17A Piezoresistor 1 R124
148 2RE1-02-500N Chip Precision Resistance 2 R3，R8
149 2CC1-10-Y5V500-104Z Chip Multilayer Capacitor 30
C141，C142，C115，C116，C123，C121，C127，C128，C159，C47，C48，C49，C50，C51，C52，C53，C54，C76，C77，C78，C64，C65，C66，
C38，C39，C40，C41，C42，C113，C122
150 2CC1-10-C0G500-101J R Chip Multilayer Capacitor 8 C398，C400，C399，C401，C404，C405，C406，C408
151 2CC1-10-C0G500-221J R Chip Multilayer Capacitor 15 C366，C367，C369，C370，C392，C393，C395，C396，C125，C134，C362，C363，C364，C365，C397
152 2CC1-10-X7R100-473K Chip Multilayer Capacitor 5 C117，C118，C119，C120，C130
153 2CC1-10-Y5V160-105Z Chip Multilayer Capacitor 16 C138，C139，C143，C144，C154，C71，C72，C73，C74，C75，C59，C60，C61，C62，C63，C114
154 2RS1-10-303J R Chip Resistance 1 R194
155 2CC1-10-X7R500-471K R Chip Multilayer Capacitor 2 C155，C156
156 2CC1-10-X5R6R3-225K R Chip Multilayer Capacitor 1 C133
157 2LL1-16-R47K R Stacked Inductor 2 FB33，FB29
158 2CC1-16-X7R500-272K Chip Multilayer Capacitor 1 C335
159 2CC1-16-C0G500-2R5B R Chip Multilayer Capacitor 1 C8
160 2CC1-16-C0G500-R50B R Chip Multilayer Capacitor 3 C510，C455，C476
161 2CC1-16-C0G500-1R0B Chip Multilayer Capacitor 5 C585，C434，C435，C441，C467
162 2CC1-16-C0G500-3R0B Chip Multilayer Capacitor 3 C380，C255，C519
163 2CC1-16-C0G500-4R0B R Chip Multilayer Capacitor 7 C515，C487，C521，C491，C493，C504，C448
164 2CC1-16-C0G500-5R0D Chip Multilayer Capacitor 12 C442，C462，C311，C469，C494，C1033，C415，C416，C274，C484，C488，C512
165 2CC1-16-C0G500-6R0C R Chip Multilayer Capacitor 4 C465，C440，C377，C381
166 2CC1-16-C0G500-7R0C Chip Multilayer Capacitor 2 C460，C3006
