Kirisun TM840 Service Manual

TM840 Service Manual
167 2CC1-16-C0G500-8R0C R Chip Multilayer Capacitor 9 C169，C500，C4007，C237，C480，C268，C520，C513，C474
168 2CC1-16-C0G500-9R0C R Chip Multilayer Capacitor 1 C269
169 2CC1-16-C0G500-100D R Chip Multilayer Capacitor 9 C199，C239，C81，C82，C35，C36，C167，C297，C101
170 2CC1-16-C0G500-110J R Chip Multilayer Capacitor 2 C529，C238
171 2CC1-16-C0G500-120J R Chip Multilayer Capacitor 2 C4006，C172
172 2CC1-16-C0G500-150J R Chip Multilayer Capacitor 1 C284
173 2CC1-16-C0G500-200J R Chip Multilayer Capacitor 3 C4011，C4016，C3005
174 2CC1-16-C0G500-220J R Chip Multilayer Capacitor 3 C445，C281，C4013
175 2CC1-16-C0G500-270J R Chip Multilayer Capacitor 3 C4019，C88，C409
176 2CC1-16-C0G500-330J Chip Multilayer Capacitor 6 C534，C461，C222，C567，C573，C309
177 2CC1-16-C0G500-390J R Chip Multilayer Capacitor 1 C12
178 2CC1-16-C0G500-470J R Chip Multilayer Capacitor 8 C198，C267，C250，C4053，C568，C259，C3007，C378
179 2CC1-16-C0G500-560J R Chip Multilayer Capacitor 4 C438，C518，C527，C481
180 2CC1-16-C0G500-101J R Chip Multilayer Capacitor 58
C313，C103，C244，C168，C273，R199，R302，R303，C453，C508，C232，C314，C315，C4021，C4022，C4034，C4035，C4036，C4037，
C4038，C4039，C4056，C4059，C4060，C4061，C137，C261，C33，C34，C32，C262，C263，C264，C265，C282，C191，C280，R304，R305，
R223，C235，C325，C292，C215，C307，C245，C419，C216，C422，C3004，C4025，C248，C4028，C330，C410，C485，C471，C473，C452
181 2CC1-16-C0G500-151J R Chip Multilayer Capacitor 22
C185，C170，C164，C219，C220，C528，C539，C456，C457，C105，C160，C258，C207，C224，C225，C249，C102，C209，C173，C391，
C570，C597
182 2CC1-16-C0G500-181J Chip Multilayer Capacitor 3 C4020，L19，L20
183 2CC1-16-C0G500-221J R Chip Multilayer Capacitor 35
C257，C444，C450，C468，C523，C502，C492，C495，C496，C503，C517，C439，C277，C459，C447，C466，C530，C339，C338，C340，
C341，C337，C336，C333，C359，C357，C332，C352，C353，C354，C356，C342，C343，C386，C387
184 2CC1-16-X7R500-331K Chip Multilayer Capacitor 3 C272，C288，C368
185 2CC1-16-C0G500-471J R Chip Multilayer Capacitor 7 C621，C626，C627，C581，C489，C531，L5018
186 2CC1-16-X7R500-102K R Chip Multilayer Capacitor 16 C312，C22，C293，C639，C4008，C619，C569，C372，C373，C374，C375，C376，C37，C355，C412
187 2CC1-16-X7R500-332K Chip Multilayer Capacitor 1 C226
188 2CC1-16-X7R500-472K R Chip Multilayer Capacitor 1 C2
189 2CC1-16-X7R500-103K R Chip Multilayer Capacitor 48
C334，C182，C166，C324，C329，C171，C252，C253，C256，C278，
C407，C463，C4014，C4015，C13，C565，C571，C162，C234，C236，C247，C279，C289，C306，C417，C421，C4026，C4027，C4000，C4001，
C4002，C4003，C4005，C458，C4012，C4017，C533，C4032，C4033，C221，C4054，C4057，C214，C213，C186，C638，C358，C351
190 2CC1-16-Y5V250-104Z R Chip Multilayer Capacitor 70
C98，C97，C285，C287，C566，C572，C486，C511，C1，C6，C10，C11，C15，C16，C18，C21，C24，C79，C80，C83，C84，C85，C86，
C87，C100，C107，C194，C227，C620，C618，C604，C205，C208，C210，C211，C233，C240，C251，C184，C260，C104，C345，C346，C349，
C350，C175，C443，C446，C464，C472，C490，C524，C4004，C163，C183，C179，C4018，C4030，C4031，C4046，C4055，C4058，C218，
C110，C112，C454，C526，C582，C602，C603，C497
191 2CC1-16-Y5V250-474Z Chip Multilayer Capacitor 1 C165
192 2CC1-16-Y5V250-105Z Chip Multilayer Capacitor 16 C344，C212，C94，C96，C99，C109，C147，C149，C157，C158，C89，C298，C152，C388，C389，C390
193 2CC1-16-Y5V100-225Z Chip Multilayer Capacitor 3 C25，C206，C385
43

Kirisun TM840 Specifications

General

Brand	Kirisun
Model	TM840
Category	Radio
Language	English
