Fig. 2.4.1a Typical Unit Mounting Arrangement
NOTES:
a) Standard Neoprene Rubber Pads are supplied along with the chiller.
b) For KAC chillers, Anchoring / Foundation bolts are not required.
2.4.2. Anti-Vibration Mounts
If minimum vibration is an important consideration, it is recommended that vibration isolators of
a suitable type be installed under the base. The isolators must be designed for the operating
weight of the unit and can be supplied by Kirloskar Chillers as an OPTIONAL ACCESSORY at
an extra cost. To further reduce the transmission of vibrations it is recommended to use flexible
connections, suitable for the system water pressure, be installed on the water connections, refer
water piping, section 2.3 for further details.
Recommended type of Isolator
Rubber-in-shear isolators
Supplementary support mounting
2.5. Water Treatment / Quality
If the unit is operating with a cooling tower (KAC units), clean and flush the cooling tower.
Make sure that the tower “blow-down” or “bleed-off” is operating. Atmospheric air contains
many contaminants, which increases the need for water treatment. This is also applicable for
liquid chiller / evaporator side.
The use of untreated water in cooling towers, closed water systems etc. frequently results in one
or more of the following:
