A Kirloskar Group Company IOM-KAC-ENG - Page 49
Operating conditions
-40T70 °C, 90% RH non-condensing
Storage conditions
-40T70 °C, 90% RH non-condensing
Index of protection
IP20 (front panel only)
Type of disconnection or micro switching
Microswitching
Ageing characteristics (operating hours)
80.000
No. of automatic operating cycles
100.000 (EN 60730-1); 30.000 (UL 60730-1)
6.5 pLDPRO Carel Keypad/Display
With the keypad/display the user can monitor the chiller’s operating conditions, system alarms,
operating schedules and has the ability to utilize diagnostic tools. With the proper authorization
level the user has the ability to clear system alarms, system lockouts, change setpoints, and
operating schedules. It allows complete management of graphics by the display of icons (defined
at application software development level), and the management of international fonts, in two
sizes: 6x8 and 12x16 pixels, and acoustic signal through piezoelectric buzzer as well.The
application software resides on the PCO board, and therefore the terminal does not require any
additional software for operation.
Technical specifications:
Display:
Type:
FSTN graphic
Backlighting:
white LED
Graphic resolution:
132x64 pixels
Text mode:
8 rows x 22 columns (font sizes 6x8pixels) 4
rows x 11 columns (font size 12x16 pixels) or
mixed modes
Character height:
2 mm (font sizes 6x8pixels)
4 mm (font size 12x16 pixels)
Size of active area:
36.94*15.98mm
Size of display area:
38.9*19.4mm
Power supply:
Voltage:
pLAN Port: power supply from pCO through
telephone cable(18…30Vdc Class II only);
Maximum power input:
0.5 W
Maximum distances:
Maximum pLAN length:
500 m with AWG22 twisted pair cable
pCO terminal distance:
50m with telephone cable 500m with AWG22
twisted pair cable and TCONN6J000 Note: to
