A Kirloskar Group Company IOM-KAC-ENG - Page 45
15. Cover for inserting the field card option
6.3. K-Smart Inputs/Outputs
Connector
Signal
Description
J1-1
G
Supply voltage A(*)
J1-2
G0
Supply voltage A(*)
J2-1
U1
Universal input/output 1
J2-2
U2
Universal input/output 2
J2-3
U3
Universal input/output 3
J2-4
GND
Common for universal inputs/outputs 1, 2, 3
J3-1
U4
Universal input/output 4
J3-2
U5
Universal input/output 5
J3-3
+Vdc
Power to active probes 4, 5
J3-4
+5VR
Power to 0 to 5 V ratiometric probes 4, 5
J3-5
GND
Common for universal inputs/outputs4, 5
J4-1
U6
Universal input/output 6
J4-2
U7
Universal input/output 7
J4-3
+Vdc
Power to active probes 6, 7
J4-4
+5VR
Power to 0 to 5 V ratiometric probes 6, 7
J4-5
GND
Common for universal inputs/outputs 6, 7
J5-1
U8
Universal input/output 8
J5-2
U9
Universal input/output 9
J5-3
U10
Universal input/output 10
J5-4
+Vdc
Power to active probes 8, 9, 10
J5-5
+5VR
Power to 0 to 5 V ratiometric probes 8, 9, 10
J5-6
GND
Common for universal inputs/outputs 8, 9, 10
J6-1
GND
Common for analogue outputs or PWM Y1, Y2, Y3
J6-2
Y1
Analogue output 1, at 0 to 10V or PWM (several types)
J6-3
Y2
Analogue output 2, at 0 to 10V or PWM (several types)
J6-4
Y3
Analogue output 3, at 0 to 10V or PWM (several types)
J7-1
DI1
Voltage free contact - digital input 1
J7-2
DI2
Voltage free contact - digital input 2
J7-3
DI3
Voltage free contact - digital input 3
J7-4
DI4
Voltage free contact - digital input 4
J7-5
GND
Common for voltage free contact - digital inputs 1, 2, 3, 4
J8
-
Connector for unipolar valve 2
