Technical specification
Square ONE Dynamics 39
Technical specification
Inputs Eight
Type
Impedance
Maximum input level
Common mode rejection
Analogue, electronically balanced female XLRs (Pin 2
hot)
10k Ohms
+22dBu
Typically, -80dB at 1kHz
Outputs Eight
Type
Minimum load impedance
Source impedance
Maximum output level
Analogue, electronically balanced male XLRs (Pin 2 hot)
2k Ohms
<60 Ohms
+22dBu
EXT KEY Inputs Eight
Type
Impedance
Maximum input level
Common mode rejection
Analogue, electronically balanced jack sockets
20k Ohms
+22dBu
Typically -60dB at 1kHz
SOLO BUS Input One
Type
Input impedance
Maximum input level
Common mode rejection
Analogue, electronically balanced female XLR
20k Ohms
+22dBu
Typically -60dB at 1kHz
SOLO BUS Output One
Type
Output impedance
Maximum input level
Signal drive capability
Output balancing
Analogue, electronically balanced male XLR
<60 Ohms
+22dBu
<600 Ohms
Typically -40dB at 1kHz
Performance Frequency response
Dynamic range
Noise floor
±0.5dBu (input to output), 20Hz to 20kHz
>117dB (22Hz to 22kHz unweighted)
<-95dBu (22Hz to 22kHz unweighted)
Compressor Threshold
Ratio
Attack
Release
Gain
Operating modes
-50dBu to +25dBu
Scale infinity to 1:1 with scale markings 5:1 and 2:1
Scale = fast to slow (100µs to 20ms)
Scale = fast to slow (50ms to 2.5s)
Scale = 0dB to +30dB
Four
Gate Threshold
Range
Attack
Release
Hold
Scale = -50dB to +25dB
Scale = -infinity to 0dB
Scale = fast to slow (10µs to 10ms)
Scale = fast to slow (2ms to 2s)
Scale = 2ms to 2s
Filter Side chain filter Scale = 40Hz to 16Hz
Terminations Audio
Power
3-pin XLRs (male and female) and 1/4” TRS balanced
jack sockets
3-pin IEC
