34
Protos 3400(X)
Saving / Loading Device Configuration
System control/Memory card/Copy configuration.
Saving / loading the complete device configuration
System control/Memory card/Copy configuration.
“Save“ configuration means that the complete device configuration
(except the passcodes) is written on the memory card.
“Load” configuration means that the complete device configuration is read
from the memory card and pogrammed.
BACKUP file generated on SmartMedia card: \BACKUP\BACKUP01.PAR
Transferring the complete device configuration
from one device to further devices
Prerequisite: The devices have the same hardware equipment, the modules are
placed in the same slots (e.g. PH 3400-032 in slot 1, OXY 3400-062 in slot 2 etc.)
1) Write device configuration of configured device on SmartMedia card:
Parameter setting/System control/Memory card/Copy configuration/Save.
2) Change to maintenance menu. Select “Close memory card”.
3) Remove the SmartMedia card.
Now you can transfer the device configuration to further identically equipped
devices.
To do so, insert the SmartMedia card containing the configuration
in the next device to be configured.
Select
Parameter setting/System control/Memory card/Copy configuration/Load.
4) Change to maintenance menu. Select “Close memory card”.
5) Remove the SmartMedia card.
