2-2 SM700_K2100_03_en 9/2007
d. Scissor arm
• Allow you to position the generator precisely and easily
• Wall-mounted with a choice of extensions
Figure 2. Side view of KODAK 2100 Intraoral X-ray System
e. On/off switch
• Contains built-in light
f. Rectangular collimator (optional)
• Different sizes adapted to films and RVG sensors
Additional options
• Separate exposure switch (if the control panel is attached to the wall
framework)
• Ceiling-mounted unit
• Floor-mounted unit
• Unit mounted on mobile stand
Table 3. Types of Scissor Arms
Extension R Span A
CG 645 47.0 cm
(18.5 in.)
170.0 cm
(66 15/16 in.)
CG 646 64.8 cm
(25.5 in.)
188.0 cm
(74 in.)
CG 648 82.5 cm
(32.5 in.)
205.0 cm
(80 11/16 in.)
