Kodak 2100 - Ceiling-Mounted Unit (Optional)

9/2007 SM700_K2100_03_en 2-3
Ceiling-mounted Unit
Figure 4. KODAK 2100 Intraoral X-ray System ceiling-mounted unit
a. High-frequency x-ray generator
b. Ceiling-mounted unit containing the high-frequency x-ray
generator’s control electronics
c. Separate timer/control unit for the x-ray generator
d. Scissor arm
e. On/off switch with built-in light
f. Rectangular collimator
b
a
e
f
c
d
