Kodak 2100 - Mounted on Mobile Stand (Optional)

2-4 SM700_K2100_03_en 9/2007
Mounted on Mobile Stand (Optional)
Figure 5. KODAK 2100 Intraoral X-ray System mounted on mobile
stand
a. High-frequency x-ray generator
b. Mobile stand containing the high-frequency x-ray generator’s
control electronics
c. Timer/control unit for the x-ray generator
d. Scissor arm
e. On/off switch with built-in light
f. Rectangular collimator
g. Handle
h. Foot brake
c
a
b
d
f
g
h
e
