Kodak Easy Share DX6490 User Manual

5
Chapter 1
Turning On the Camera
! To turn on the camera, rotate the Mode
dial.
Turn clockwise for still capture modes.
Turn counterclockwise for video mode.
The mode light blinks while the camera
performs a self-check, then glows when
the camera is ready to take pictures or
videos.
The EVF (electronic viewfinder) or the
LCD screen turns on, depending on which
display was last used (see page 7).
The name and description of the capture
mode you chose is displayed on the screen
for 3 seconds.
To identify the status icons that appear
on the screen, see page 8.
Mode light,
LCD screen
EVF
On position

Kodak Easy Share DX6490 Specifications

General

Sensor Type	CCD
Effective Pixels	4.0 MP
Optical Zoom	10x
Digital Zoom	3x
Focal Length	38 - 380 mm
LCD Screen Size	2.2 inches
Viewfinder	Electronic
Storage Media	SD/MMC card
Max Shutter Speed	1/1700 sec
Min Shutter Speed	16 sec
ISO Range	80 - 800
Video Resolution	640 x 480
Battery Type	Lithium-Ion
Aperture Range	f/2.8 - f/8
