Kodak EasyShare Printer Dock Plus - Product Features and Component Identification; Back;Top;Side View Components

Product features
ii www.kodak.com/go/support
Back/top/side view
1 Universal camera insert
(installed as shown)
6 Cooling vents
2 Locator pin for camera 7 Slot for paper path
3 Camera connector 8 Color cartridge (installed as shown)
4 Power connector (DC-in) 9 Cartridge door
5 USB connector (to computer)
5
79 8
4
1 2 3
6
