Product features
www.kodak.com/go/support
i
Front/top/side view
1 Paper light 12 Cancel button
2 Battery charging lights/
Refresh button
13 Picture Size button
3 Color Cartridge light 14 Picture Size lights , , ,
4 Transfer button/light 15 Accessory door
5 Slide Show button/light 16 SD/MMC card slot light
6 Auto-Enhance button/light 17 SD/MMC card slot
7 IR sensor (for optional remote
or infrared device)
18 USB device connector light
8 Paper tray 19 USB device connector (for optional Kodak
card reader or PictBridge compatible device)
9 Paper tray door
10 Print button/light 20 Audio/Video (A/V) out connector
(for television viewing)
11 4-way control
4
10
7
14
13
6
9
2 31
11
8
15
17
18
19
20
12
5
16
