5-10 A-61550 February 2010
5. Lift and remove each core assembly and slide the tires off of the
core.
6. Install each new tire by gently stretching it over the core.
IMPORTANT:
• Do not overstretch the tire; it may tear.
• Make sure that the tire is centered on the core and lies flat.
7. Replace each core assembly in the feed module and snap it into
place.
8. Reinstall the feed module.
9. Reinstall the front roller cover.
10.Close the scanner cover with both hands; push it down firmly until it
latches into place.
