A-61651 December 2009 1-5
Printer access view Even if you do not have the Kodak Enhanced Printer Accessory, you will still
need to access this area of the scanner. The feed module release knob is
located in this area.
1Printer cable — this cable connects directly to the printer carrier to allow
communication to the Enhanced Printer.
2 Enhanced Printer carrier/cartridge — allows front printing on
documents. This is only present if the Enhanced Printer Accessory is
installed.
3 Print positions — 8 print positions are available.
4 Feed module release knob — turn this knob to release the feed module
from it’s position for cleaning or replacing. The arrow on the release knob
should be pointing to the left when the feed module is engaged; and right
when the feed module is disengaged.
