Chapter 2 CVS-833/833C
Equipment composition
2.2 Essential option
No Item name Ratings Application Weight/length
1 TD-500T-2 600W: 50kHz/200kHz
Material: plastic
For inner-hull
0.7kg / 9m
2 TD-500T-3 600W: 50kHz/200kHz
Material: zinc bronze
For through-hull
1.5kg / 9m
3
Transducer
For CVS-833 (600W)
Or equivalent 600W: 50kHz/200kHz
The connector (3-pin or 8-pin) must be
prepared.
-
4 TD-501T-3 1kW: 50kHz/200kHz
Material: zinc bronze
With temperature sensor
3.4kg / 9m
5 TD-501C 1kW: 50kHz/200kHz
Material: rubber molded
For Inner-hull, Bottom-hull or Broadside
The connector (3-pin) must be prepared.
4.2kg / 9m
6
Transducer
For CVS-833C (1kW)
Or equivalent 1kW: 50kHz/200kHz
The connector (3-pin or 8-pin) must be
prepared.
-
2.3 Optional items list
No Item name Ratings Application Weight/length
1 Speed and
Temperature sensor
ST-80 For the transom installation. Material:
Plastic. A connecting cable attached.
0.3kg
ST-90 For the through-hull installation. Material:
plastic. A connecting cable attached.
0.5kg
ST-100 For the through-hull installation. Material:
zinc bronze. A connecting cable attached.
1kg
2 Connecting cable CW-60-10M A BNC Connector on one end, crimp
terminals on the other
10m
CW-153A-5M 6-pin connectors on both ends 5m
CW-154A-5M 6-pin connector on one end and fly-leads on
the other
5m
CW-155-5M A BNC Connector on one end, 6-pin
connector on the other
5m
CW-351/327-5M A 6-pin waterproof connector on one end
and a 6-pin connector on the other
5m
CW-352/328-5M A BNC Connector on one end, crimp
terminals on the other
5m
CW-506-5M 5-pin connector on one end and fly-leads on
the other
5m
3 Inner hull kit MFB-04 Material: Resin. For the transducer fitting. 1.3kg
4 Junction box JB-12
1 Input 3 outputs, 3 Inputs 1 output､
For the navigator connection
0.42kg
5 Rectifier PS-003A With 5A fuse (2 pcs) 2.8kg
6 Power cable VV-2D8-3M Both ends dressed and tinned 3m
2-2 0093132902-02
