Chapter 6 CVS-833/833C
Using the Menu
6.2.2 Selecting Initial Menu
Operating procedure of the Initial Menu is the same as Main Menu.
6.3 Exiting from the Menu
6.3.1 Exiting from Main Menu
MENU
Press the MAIN menu key repeatedly until the menu display
disappears.
6.3.2 Exiting from Initial Menu
Open Initial Menu and select “9. EXIT”. For detail, refer to Para. 6.11.9 “Exiting Initial Menu”.
6.4 MENU 1
Using MENU 1, the following functions can be used:
1. Selecting a zooming range for the bottom lock image, bottom discrimination image, bottom zoom
image and zoom image
2. Setting a zooming start position for the zoom range
3. Selecting the intensity of interference rejection
4. Selecting the intensity of noise rejection
5. Selecting the background color
6.4.1 Zoom Range
Using this sub menu, you can select a zooming range of the following image modes; Bottom Lock
image, Bottom Discrimination image and Zoom image. To select:
1. Move the cursor to the left using the RIGHT arrow key and select Zoom Range using the UP or
DOWN key.
2. Move the cursor to the left or right using the LEFT or RIGHT key to select your desired zoom range.
3. Initial and selectable zoom ranges are as follows:
Initial setting: 10ft、2.5 m/J.fm/fm/l.fm
Selective range：
10､20､40､80､160､320ft
2.5,5,10,20,40,80 m/J.fm/fm/l.fm
: Mod
: MENU No. Select
2.5
0
OFF 1 2
0
1 2 3 4
Zoom Range
Zoom Start
Intrf Rejection
Noise Rejection
Background Color
Return
MENU 1
MENU 2
MENU 3
MENU 4
MENU 5
MENU 6
MENU 7
MENU : Exit
Figure 6.2 Setting up Zoom Range in Menu 1
