CVS-833/833C Chapter 1
General information
Chapter 1 General information
1.1 General
The CVS-833/833C series of sounder is composed of two main units, a display unit and a transducer
unit. Transmitting power level can be selected from 600 W (CVS-833) and 1 KW (CVS-833C), using the
same dual-frequency transducer type for 50 KHz and 200 KHz.
The display unit uses a high brightness, 8” TFT (Thin Film Transistor) display to allow an easy viewing
even in daytime operation. The operation is simple and straightforward, using dedicated rotary controls
and user-friendly menus.
By pressing the AUTO key the unit is set to hands-free operation, in which the gain and depth range are
automatically selected to an optimized level by an internal micro-controller chip.
1.2 Applicable standard
The CVS-833/833C is designed and tested to comply with the international standard of IEC-60945 3
rd
edition that defines the general requirements of electronic maritime equipment.
1.3 Type name of component units
Type name Output Display type Transducer type
CVS-833 600W CVS-833 TD-500T-2 or TD-500T-3
CVS-833C 1kW CVS-833C TD-501T-3 or TD-501C
1.4 Software type used
Software type name Application
KM-E05 CVS-833
KM-E06 CVS-833C
1.5 System configuration
The CVS-833/833C system is configured as follows: (Refer to Figure 1.1 for the system configuration
diagram)
93132902-00 1-1
