27
Specifications
Nov. 10 2023 F
※ These specifications are subject to be changed without notice for the sake of
improvement.
Model
C300A
Outer Dimentions
W:370mm×D:370mm×H:296mm
Weight
24kg
Power Source
AC 100V ~ 240V(Single Phase) ±10% 50Hz/60Hz
Power Consumption
33W(Rating) 182W(Max) At AC100V
Settable Cutting
Length
0.1mm~99999mm
Cutting Tolerance
Less than ±(0.1+0.0005×L)mm
L=Cutting Length (Depending on the wire)
Settable Strip
Length
Front End 0.1mm~999mm(Possible Input Value)
Rear End 0.1mm~999mm(Possible Input Value)
Wire
Processaboe
Type
AVSS,VSF,IV,KV,UL,Teflon,Glass Wire, etc.
Size
AWG#16(1.25sq)~#36(0.01sq)
(Depending on the type of wire)
Outer Size
Max.φ2.5mm (Depending on the wire)
Wire Feeding Speed
Variable
Blade Material
Ultra Micro-Parculate Mixed Metal
Engine
Stepping Motor
