Kohler KD62V12 - Page 107

Repair
Driving gear
Information
If the flow of silicon oil is very slow, open the upper sample opening 1.
u When the sample container is 75% full, install a cap on the end of the sample container.
u Tighten the sample container cap by hand.
Information
Do not use any tool to tighten the sample container cap.
u Install a new screw plug into the upper sample opening 1 if it has been opened.
Information
Always replace the screw plug.
u Tighten the screw plug to torque. (For more information see: Tightening specifications,
page 108.)
u Remove the sample container from the lower sample opening 3.
Information
Make sure that silicon oil does not leak from the sample container.
u Install a cap on the sample container.
u Tighten the sample container cap by hand.
u Install a new screw plug into the lower sample opening 2.
Information
Always replace the screw plug.
u Tighten the screw plug to torque. (For more information see: Tightening specifications,
page 108.)
u Fill in the sample form delivered with the sampling kit.
u Place the sample container and form into the padded envelope and send them for analysis.
Specific values
Not applicable.
