Product description
Technical description
Fig. 2: Diesel engine / view from the free end
FE
Free end 14 Exhaust gas connection
10 High-temperature coolant pump 15 Lifting lug
11 High-temperature thermostat housing 16 Oil cooler
12 Low-temperature coolant pump 17 Oil filter
13 Low-temperature thermostat housing
Fig. 3: Diesel engine / view from the free end
FE
Free end 21 Cylinder head cover
18 Torsional vibration damper cover 22 Charge air pipe
19 Engine control unit 23 Starter
20 Straight air intake 24 Oil pan
18
© 2022 by Kohler Co. All rights reserved.
KD62V12 33525088601_8_1 EN_US
2022-09
