Kohler KD62V12

Repair
Cooling system
Overview
Fig. 212: Task overview
1
Venting LT turbocharger 7 Venting LT charge air cooler
2 Flange joint 8 Flange joint
3 Venting LT charge air cooler 9 Venting HT thermostat
4 T connector 10 Venting LT turbocharger
5 Screw (M10) 11 Venting HT collecting pipe
6 Distribution block
KD62V12 33525088601_8_1 EN_US
2022-09
